| Physical |
Dimensions (mm) |
109mm x 91mm x 15mm (length x breadth x height) |
| Weight (g) |
125 – Li-ion battery |
| 117 – AAA |
| Processor |
Processor |
PB03F |
| Communication |
Bluetooth (For BLE Pairing, Stage Mode) |
BLE 5.2 |
| USB |
Not Available |
| Battery |
Battery Type |
3.7V Li-ion battery/AAA 3Cell |
| Battery Rated Voltage |
3.3V |
| Battery Capacity |
500mAh (For rechargeable) |
| Battery Life |
4 hours |
| Charging |
2.5 hours |
| Speaker |
Buzzer |
For Interactive Sound |
| Connectivity |
Servo Port |
Servo Port/ with Sensor |
| Programmable LED |
RGB LED |
Two Programmable RGB LED |
| Hardware Interaction |
Tactile Switches |
3-way Power Switch |
| Power Panel |
Switches |
Power Indicators (Displays the power switch’s status: Button Coding or Picto Coding) |
| Sensors |
IR Sensors |
| Indicators |
Two LED indicators indicate the Mode, and another Low Battery Indicator indicates Low Battery Voltage |
| Buttons |
9 Programmable Button |
| Motors |
DC Motors |
| Accessories |
Pen holder |
1 Pen holder provided |
